24-channel temperature acquisition
Designed and manufactured in India
ThermoDAQ for Industrial and Cryogenic Temperature Monitoring
ThermoDAQ is a standard 24-channel temperature acquisition product for synchronized thermal validation, environmental testing, laboratory monitoring, and production test benches. It supports configurable thermocouple, RTD, thermistor, and selected cryogenic sensor channels with Ethernet PC software, output channels, and customizable input connectors.
Designed and manufactured in India
Standard product architecture
One temperature DAQ platform for mixed sensor wiring
ThermoDAQ is positioned as a standard product with configurable channel build options. The hardware can be supplied with connector layouts and channel grouping matched to thermocouples, RTDs, thermistors, selected cryogenic sensors, and output wiring without changing the product family.
Thermocouple inputs
Configurable J, K, T, E, N, R, S, and B thermocouple channels with cold-junction compensation.
RTD channels
PT100 and PT1000 RTD measurement options with 2-wire, 3-wire, or 4-wire wiring configurations.
Thermistor support
NTC and PTC thermistor configurations for compact thermal monitoring and embedded sensor setups.
Cryogenic channels
Dedicated low-temperature sensor channel options for cryogenic test rigs and low-temperature validation.
Output channels
Configurable outputs for alarm relay, interlock, heater enable, control reference, or external system integration.
Custom connectors
Input connector type, pinout, channel grouping, shield termination, and labelling can be customized.
Technical specification
24-channel temperature acquisition engine
Final channel grouping and connector configuration can be selected based on the sensor mix, cryogenic measurement requirement, output wiring, enclosure format, and software workflow.
- System type
- 24-channel industrial temperature data acquisition system with Ethernet PC software.
- Temperature inputs
- 24 synchronized temperature acquisition channels with configurable sensor grouping.
- Sensor support
- Thermocouple, PT100/PT1000 RTD, NTC/PTC thermistor, and selected cryogenic temperature sensor options.
- Cryogenic channels
- Dedicated low-temperature channel group options for cryogenic sensor measurement and logging.
- Output channels
- Configurable output channels for alarm, interlock, heater/control reference, or PLC/test-rig integration.
- Communication
- Ethernet TCP/IP interface for configuration, live monitoring, logging, and export.
- Input connectors
- Customizable connector layout including terminal type, pinout, sensor grouping, shielding, and labels.
- Resolution
- High-resolution temperature measurement with 0.1 deg C practical display resolution target, subject to sensor type.
- Thermocouple features
- Linearization, cold-junction compensation, open sensor diagnostics, and engineering-unit display.
- Logging software
- Live numeric view, trend plots, alarm limits, channel status, CSV export, and report-ready data files.
- Calibration
- Channel-wise gain/offset calibration with stored coefficients and factory test documentation.
- Protection
- Protected input front ends, sensor fault detection provisions, shield termination, and robust enclosure design.
- Product format
- Rackmount or benchtop industrial enclosure options with standard product configuration and custom wiring variants.
Software and applications
Temperature logging, trends, alarms, and export
ThermoDAQ connects to Atmen logging software for synchronized acquisition, trend visualization, channel configuration, alarms, post-processing, and CSV/report export.
Live temperature dashboard
Real-time numeric monitoring for all configured channels with sensor status and alarm state visibility.
Trend plotting
Single-channel and multi-channel plots for warm-up, cool-down, soak, thermal cycle, and stability tests.
Channel configuration
Configure sensor type, labels, scaling, filtering, alarm limits, sample rate, and output action mapping.
Export and analysis
CSV logs and report-ready exports for traceability, thermal characterization, validation, and audits.
24-channel temperature DAQ for thermocouple, RTD, thermistor, and cryogenic sensor logging
ThermoDAQ is built for test benches, environmental chambers, thermal cycling rigs, battery and electronics validation, cryogenic experiments, process monitoring, and production quality checks. The product combines temperature data acquisition, Ethernet connectivity, customizable input connectors, configurable output channels, alarm handling, graph plotting, and data export in one industrial measurement platform.
